10W LED HID Replacement; 5000K; Medium base; 12-24V DC Only
General
Status | Active |
Watts | 10 |
Incandescent Equivalent | 90 |
HID Equivalent | 30 |
Volts | 12V-24V |
Shape | Corncob |
Base | Medium |
ANSI Base | E26 |
Finish | Clear |
CCT (Kelvin) | 5000 |
Temperature | Natural Light |
CRI | 80+ |
Lumens | 1200 |
Beam Spread | 330 |
Dimmable | Non-Dimmable |
Hours Rated | 50000 |
Lamp Type | Corncob |
Technology | LED |
Min Compartment Size | Length 8.50 in. Width 6 in. Depth 6 in. |
Electrical
Watts | 10 |
Incandescent Equivalent | 90 |
HID Equivalent | 30 |
Volts | 12V-24V |
Working Voltage | 12V-24V DC Only |
CCT (Kelvin) | 5000 |
Temperature | Natural Light |
CRI | 80+ |
Lumens | 1200 |
Beam Spread | 330 |
Dimmable | Non-Dimmable |
Dimming Type | N/A |
Hours Rated | 50000 |
Burning Position | Universal |
Operating Temperature | -25C (-13F) to a maximum of +45C (+113F) |
Physical
MOL | 5.81 |
MOD | 2.44 |
Shape | Corncob |
Base | Medium |
ANSI Base | E26 |
Finish | Clear |
Lens Finish | Clear |
Housing Color | White |
Additional Information
Enclosure Rating | Enclosed Rated Lamp |
Min Compartment Size | Length 8.50 in. Width 6 in. Depth 6 in. |
Rated For Enclosed Fixture | Yes |
IP Rating | IP64 |
Warranty | 5 Year Limited - Hi-Pro |
Compliance
Safety Listing | Not Applicable |
Energy Star | No |
DLC Approved | No |
CEC Status | Non-Compliant |
RoHS Compliant | Yes |
SDS Sheet | LED Lamp |
Packaging
Each UPC | 045923097539 |
Each Quantity | 1 |
Each Length (in.) | 2.87 |
Each Width (in.) | 2.87 |
Each Height (in.) | 6.46 |
Each Weight (lb.) | 0.55 |
Each Cube (CuFt.) | 0.0299 |
Pack Type | Box |
Inner Quantity | 0 |
Inner Length (in.) | 0.00 |
Inner Width (in.) | 0.00 |
Inner Height (in.) | 0.00 |
Inner Weight (lb.) | 0.00 |
Inner Cube (CuFt.) | 0.0000 |
Case UPC | 10045923097536 |
Case Quantity | 48 |
Case Length (in.) | 18.50 |
Case Width (in.) | 12.40 |
Case Height (in.) | 13.98 |
Case Weight (lb.) | 32.19 |
Case Cube (CuFt.) | 1.7997 |
